"DrillForceMeister" TIS L/D=5 indexable head drill.
Product Specifications
| Cutting Diameter Maximum (mm) | 11.9 mm |
| Cutting Diameter Minimum (mm.) | 11.5 mm |
| Flange Diameter (mm) | 20 mm |
| Connection Diameter Machine Side (Inch) | 1-1/4" |
| Overall Length (mm) | 98.95mm |
| Point Length (Inch) | 0.201" |
| Shank Length (Inch)) | 2.362" |
| Shank Length (mm) | 5.683" |
| Insert Seat Size Code (SSC) | 28 |
| Coolant Supply Property (CSP) | Through Hole |
| Application | General Drilling |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.4685"
Minimum Cutting Diameter (Decimal Inch):
0.4527"
Flange Diameter (Decimal Inch):
0.7870"
Body Material:
Steel
Overall Length (Decimal Inch):
3.8960"
Point Length (Decimal Inch):
0.0690"
Shank Length (Decimal Inch):
1.8900"
Usable Length (Decimal Inch):
1.4570"
interval quantity:
1
