Tungaloy 6706779 | TID170F20-3 17.90mm Diameter x 127.70mm OAL Steel Replaceable-Tip Drills

$415.40
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.7047"
Minimum Cutting Diameter (Decimal Inch):
0.6692"
Flange Diameter (Decimal Inch):
0.9840"
Body Material:
Steel
Overall Length (Decimal Inch):
5.0280"
Point Length (Decimal Inch):
0.1020"
Shank Length (Decimal Inch):
1.9690"
Usable Length (Decimal Inch):
2.1260"
interval quantity:
1
SKU:
23024904
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping

Related Products

"DrillMeister" indexable head drill with flanged shank.


Product Specifications
Cutting Diameter Maximum (mm)17.9 mm
Cutting Diameter Minimum (mm.)17 mm
Flange Diameter (mm)25 mm
Connection Diameter Machine Side (Inch)1-1/4"
Overall Length (mm)127.70mm
Point Length (Inch)0.143"
Shank Length (Inch))2.362"
Shank Length (mm)3.007"
Insert Seat Size Code (SSC)24
Coolant Supply Property (CSP)Through Hole
ApplicationGeneral Drilling
