3M double coated film tape 9589 features a high-density polyethylene carrier with synthetic rubber adhesive on a densified kraft paper liner. It combines high initial adhesion and good holding power to ensure it bonds to a variety of materials. The paper liner has been specially treated to improve its strength and removability characteristics.
Long-Lasting Performance- 3M Double Coated Film Tape 9589 is a 9.0 mil double coated tape with a high tack synthetic rubber adhesive on a high density polyethylene (HDPE) carrier. 3M Adhesive 760 provides excellent quick stick and bonds together a wide variety of materials, with a build-up over 24 hours that allows for proper placement of bonded materials. It features excellent adhesion to both high surface energy and low surface energy substrates and is an excellent choice for many indoor and room temperature applications such as carpet installation. The HDPE carrier adds dimensional stability to aid in removal while also providing easier handling during slitting, lamination and die cutting, and it tears by hand for quick and easy application. The tape is mounted on a 3.7 mil 62 lbs. densified kraft paper liner which has been specially treated to improve strength and removability from high internal strength surfaces. This tape can withstand short-term temperatures of up to 200°F.
- Carpet installation
- General industrial mounting, joining and splicing
- Miscellaneous joining and holding where high initial tack is required
- Die-cutting and laminating applications
- High density polyethylene carrier provides dimensional stability and tears by hand
- Adhesive removes cleanly from many surfaces to ensure a relatively easy clean-up process
- Excellent quick stick and high adhesion ensure a reliable bond to a variety of substrates
Product Specifications
Manufacturer Part Number | 7000048619 |
Adhesive Type | Synthetic Rubber |
Core Size (Decimal Inch) | 3.000" |
Indoor/Outdoor | Both |
Master Size Length (mm) | 131.70mm |
Overall Length | 36.000yd |
Overall Thickness | 3.000mil |
Overall Width (Decimal Inch) | 0.700" |
Primary Liner | 62# Densified Kraft Paper (DK) |
Primary Liner Thickness (mm) | 0.09mm |
Product Color | White |
Product Number | 9589 |
Product Type | Splicing & Tabbing Tape |

Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
3M
Adhesive Type:
Synthetic Rubber
Core Size (Inch):
3"
Core Size (Decimal Inch):
3.0000"
Core Size (mm):
76.20mm
Master Size Length (Inch):
5-3/16"
Master Size Length (Decimal Inch):
5.1900"
Master Size Length (mm):
131.70mm
Color:
White
Material:
Cardboard
Primary Liner Thickness (mm):
0.09mm
Overall Width (Inch):
7/10"
Overall Width (Decimal Inch):
0.7000"
Overall Width (mm):
19.05mm
Overall Length (yd):
36.000yd
Overall Length (mm):
32.91mm
Overall Thickness (mil):
3.000mil
