Dormer E1192NO9 | 1.7717" Diameter x 6.2992" OAL 6 Flute Bright Coated Tap Set

$917.55
Ships:
From Partner Facility
Ships:
From Partner Facility
SKU:
15022326
UPC:
7320760084588
Weight:
141.20 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping

Set of straight flute serial taps NO9 for British Standard Pipe thread G 2" with 11 TPI and Normal class of fit, consisting of 1 tap with a truncated thread profile and 3.5-5xP plug lead and 1 tap with a 2-3xP semi-bottoming lead, dimensions according to DIN 5157 standard with 45.0mm shank and 35.0mm square drive, HSS with bright finish for 1.5xD through or blind hole threading in free machining and plain carbon steel and non-ferrous metals.


Product Specifications
Connection Diameter (Inch)1.7717"
Overall Length (Inch)6.2992"
Clamping Width (mm)35mm
Thread Diameter (mm)59.61mm
No of Flutes6
Thread Diameter Size2"
Threading Length (mm)40mm
Material CodeHSS
Thread Tolerance ClassNormal
Cutting DirectionRight Hand
CoatingBright
Tap Chamfer StyleC 2-3
Surface ColorBright Silver
Thread FormG-British standard pipe fastening-G series
