Features:
- Multi-functional tool. Wear resistant sub-micro grain carbideAxial coolant holes for maximum chip evacuation
- Axial
Product Specifications
| End Style | Corner Radius |
| End Type | Rough/Finish |
| Size | 20 mm |
| Applicable Material | Universal Materials |
| Type | Corner Radius |
| Length Group | Regular |
| Features: | High performance design for universal applications Coolant fed design |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 35/38 Degree |
| Shank Diameter (mm) | 20 mm |
| Shank Tolerance | h5 |
| Shank Style | HB |
| Overall Length (mm) | 104 mm |
| Flute Length (mm) | 38 mm |
| Flute Direction | Right Hand |
| Corner Radius | 1.5 mm |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Mill Diameter (Inch):
25/32"
Mill Diameter (Decimal Inch):
0.7875"
Mill Diameter (mm):
20mm
Number of Flutes:
4
Corner Radius (Inch):
1/16"
Corner Radius (Decimal Inch):
0.0591"
Corner Radius (mm):
1.5mm
Length of Cut (Inch):
1-1/2"
Length of Cut (Decimal Inch):
1.4961"
Length of Cut (mm):
38mm
Material:
Carbide
Finish/Coating:
TIALN
Shank Diameter (Inch):
25/32"
Shank Diameter (Decimal Inch):
0.7875"
Shank Diameter (mm):
20mm
Application:
Finisher
Overall Length (Inch):
4-3/32"
Overall Length (Decimal Inch):
4.0945"
