Features:
- Designed for trochoidal milling strategies. Reduced radial cuts with longer depth of cuts
- Allows for higher feed rates. Chip breaker flute design helps control chip size and improve performance
Product Specifications
| Chamfer Form | |
| Size | 3/4" |
| Applicable Material | Titanium, Stainless Steel, Nickel Alloys |
| Application | Finisher |
| Type | Trochoidal |
| Length Group | 3 x D |
| Coolant Fed | Axial |
| Coating/Finish | TIN/TIALN |
| Material | Carbide |
| Number of Flutes | 5 |
| Helix Angle (Degrees) | 38/42 Degree |
| Shank Diameter (mm) | 3/4" |
| Shank Tolerance | h6 |
| Shank Style | HB |
| Overall Length (mm) | 5" |
| Flute Length (mm) | 2-1/4" |
| Flute Direction | Right Hand |
| Corner Radius | 0.090" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Inch):
3/4"
Cutting Diameter (Decimal Inch):
0.7500"
Shank Diameter (Inch):
3/4"
Corner Radius (Decimal Inch):
0.0900"
Cutting Edge Material:
Carbide
Flute Length (Inch):
2-1/4"
Number of Flutes:
5
Flute Direction:
Right Hand
Finish/Coating:
TiN/TiAlN
Tool Type:
Square End
Application:
Finishing
Overall Length (Inch):
5"
Overall Length (Decimal Inch):
5.0000"
