Product Specifications
| Chamfer | 4-5 P |
| Chamfer Form | B |
| Class | Oversize |
| Pitch | 0.5 |
| Size | M 3 |
| Thread Limit | 6GX |
| Thread Standard | M |
| Coolant Fed | No |
| Coating/Finish | TIN-70 |
| Material | HSSE-PM |
| Shank Diameter (mm) | 3.5 mm |
| Dimension Standards | DIN/DIN |
| Shank Tolerance | h9 |
| Overall Length (mm) | 56 mm |
| Flute Direction | Straight |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Shank Diameter (mm):
3.50mm
Cutting Edge Material:
HSSE-PM
Thread Size:
M 3 x 0.5
Thread Standard:
M
Number of Flutes:
3
Flute Direction:
Straight
Finish/Coating:
TiN-70
Tool Type:
Rekord B-Z
Class of Fit:
Oversize
Application:
Spiral Point Taps
Overall Length (mm):
56.00mm
interval quantity:
1
