Emuge GFT9B816.9677 | 0.561" Diameter x 1/2" Shank x 3-1/4" OAL x 4 Flutes TICN Coating Carbide Multi-Thread Mill

$253.89 $236.12
(You save $17.77)
Brand:
Emuge
Cutting Diameter (Decimal Inch):
0.5610"
Shank Diameter (Inch):
1/2"
Cutting Edge Material:
Carbide
Thread Length (Decimal Inch):
0.8030"
Flute Length (Decimal Inch):
0.8030"
Thread Size:
1/4 - 3/8-18
Thread Standard:
NPT
Threads per Inch (TPI):
18 TPI
Number of Flutes:
4
Flute Direction:
Left Hand
Finish/Coating:
TiCN
Tool Type:
MULTI-THREAD MILL
Application:
Thread Milling
Overall Length (Inch):
3-1/4"
interval quantity:
1
SKU:
25212379
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Features:

  • For economical production of internal pipe threads in a wide range of materials
  • Optimized cutting geometry that works well in a job shop enviroment with multiple materials

Product Specifications
EDP NumberGFT9B816.9677
Pitch (Inch)18"
Size1/4 - 3/8
Applicable MaterialUniversal Materials
ApplicationFull Profile
TypeMulti-Thread Mill
CoatingTICN
MaterialCarbide
Flutes4
Flute / Helix Angle15 Degree
Shank (Inch)1/2"
Shank Toleranceh6
Shank StyleHA
Overall Length (Inch)3-1/4"
Flute Length (Inch)0.803"
Flute DirectionLeft Hand
