Features:
- For economical production of internal pipe threads in a wide range of materials
- Optimized cutting geometry that works well in a job shop enviroment with multiple materials
Product Specifications
| EDP Number | GFT9B856.9679 |
| Pitch (Inch) | 11.5" |
| Size (Inch) | 1" - 2" |
| Applicable Material | Universal Materials |
| Application | Full Profile |
| Type | Multi-Thread Mill |
| Coating | TICN |
| Material | Carbide |
| Flutes | 5 |
| Flute / Helix Angle | 15 Degree |
| Shank (Inch) | 3/4" |
| Shank Tolerance | h6 |
| Shank Style | HA |
| Overall Length (Inch) | 3-3/4" |
| Flute Length (Inch) | 1.260" |
| Flute Direction | Left Hand |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
