Features
- Now 3 coolant options all in one!
- Coolant through the spindle
- DIN Coolant through the flange option
- Coolant through the body
- All ground body
- Premium balanced to 30,000 RPM
- Comes complete with certificate
Product Specifications
| Manufacturer Part Number | 522148 |
| Shank Type | Taper Shank |
| Taper Size | CAT50 |
| Hole Diameter (Inch) | 5/8" |
| Nose Diameter (Decimal Inch) | 1.65" |
| Projection (Decimal Inch) | 1.75" |
| Through Coolant | Yes |
| Balanced to (RPM) | 25000 RPM |
| Seat Depth (Decimal Inch) | 1.61" |
| Set Screw | 9/16"-18 |
| Notes | Stubby |
| Product Type | End Mill Holder & Adapter |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
