Product Specifications
| Minor Diameter (Decimal Inch) | 0.0120" |
| Length of Cut (Decimal Inch) | 0.0330" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Angle per Side | 60 Degree |
| Included Angle | 120 Degree |
| Right Hand Teeth | 12 |
| Left Hand Teeth | 6 |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Angle Per Side:
60 Degree
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Finish/Coating:
AlTiN
Material:
Carbide
Length of Cut (Decimal Inch):
0.0330"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Ships:
From Partner Facility
