Product Specifications
| Mill Diameter (Decimal Inch) | 0.3750" |
| Mill Diameter (Inch) | 3/8" |
| Neck Diameter (Decimal Inch) | 0.1870" |
| Neck Diameter (Inch) | 3/16" |
| Cutter Width (Decimal Inch) | 0.2500" |
| Cutter Width (Inch) | 1/4" |
| Neck Length (Decimal Inch) | 0.5620" |
| Neck Length (Inch) | 9/16" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Radial Depth Of Cut (Decimal Inch) | 0.0840" |
| Corner Radius (Decimal Inch) | 0.0300" |
| Number of Flutes | 8 |
| Reach Multiple | (1.5x) |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Coating | AlTiN |
| Top Corner Radius | 0.03 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Milling Diameter (Inch):
3/8"
Milling Diameter (Decimal Inch):
0.3750"
Cutting Width (Inch):
1/4"
Cutting Width (Decimal Inch):
0.2500"
Corner Radius:
0.0300"
Neck Length (Inch):
9/16"
Neck Length (Decimal Inch):
0.5620"
Material:
Solid Carbide
Finish/Coating:
AlTiN
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Tooth Configuration:
Straight
Ships:
From Partner Facility
interval quantity:
1
