Product Specifications
| Mill Diameter (Decimal Inch) | 0.3934" |
| Neck Diameter (Decimal Inch) | 0.1810" |
| Length Of Cut (Decimal Inch) | 0.3660" |
| Neck Length (Decimal Inch) | 0.3120" |
| Neck Length (Inch) | 5/16" |
| Overall Reach (Decimal Inch) | 0.6790" |
| Overall Length (Decimal Inch) | 2.7500" |
| Overall Length (Inch) | 2-3/4" |
| Radius (Decimal Inch) | 0.1967" |
| Wrap Angle | 300 Degree |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 0.4375" |
| Shank Diameter (Inch) | 7/16" |
| Coating | Uncoated |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Wrap Angle:
300 Degree
Mill Diameter (Decimal Inch):
0.3934"
Length of Cut (Decimal Inch):
0.3660"
Neck Length (Decimal Inch):
0.3120"
Number of Flutes:
4
Shank Diameter (Inch):
7/16"
Shank Diameter (Decimal Inch):
0.4375"
Overall Length (Inch):
2-3/4"
Overall Length (Decimal Inch):
2.7500"
Finish/Coating:
Uncoated
Material:
Carbide
Ships:
From Partner Facility
IsDiscontinued:
