Product Specifications
| Manufacturer Part Number | 89915 |
| Cutter Diameter (Decimal Inch) | 0.750" |
| Cutter Diameter (Inch) | 3/4" |
| Length of Cut (Decimal Inch) | 2.250" |
| Length of Cut (Inch) | 2-1/4" |
| Overall Length (Decimal Inch) | 5.000" |
| Overall Length (Inch) | 5" |
| Corner Radius (Decimal Inch) | 0.060" |
| Number of Flutes | 5 |
| Shank Diameter (Decimal Inch) | 0.750" |
| Shank Diameter (Inch) | 3/4" |
| Coating | TPLUS |
| Center Cutting | Yes |
| Coolant Through | Yes |
| Product Type | Corner Radius End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Helical Solutions
Cutter Diameter (Inch):
3/4"
Cutter Diameter (Decimal Inch):
0.7500"
Cutter Diameter (mm):
19.05mm
Length of Cut (Inch):
2-1/4"
Length of Cut (Decimal Inch):
2.2500"
Length of Cut (mm):
57.15mm
Overall Length (Inch):
5"
Overall Length (Decimal Inch):
5.0000"
Overall Length (mm):
127.00mm
Corner Radius (Inch):
3/50"
Corner Radius (Decimal Inch):
0.0600"
Corner Radius (mm):
1.52mm
Shank Diameter (Inch):
3/4"
Shank Diameter (Decimal Inch):
0.7500"
Shank Diameter (mm):
19.05mm
Number of Flutes:
5
Finish/Coating:
TPLUS Coated
