Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.4900" |
| Hand Direction | Right Hand |
| Finish/Coating | Uncoated |
| Max Bore Depth (Inch) | 4-1/2" |
| Max Bore Depth (Decimal Inch) | 4.500" |
| Projection (Decimal Inch) | 0.1220" |
| Shank Diameter (Inch) | 1/2" |
| Shank Diameter (Decimal Inch) | 0.5000" |
| Centerline Offset (Decimal Inch) | 0.2400" |
| Radius (Decimal Inch) | 0.0060" |
| Face Dimension (Inch) | 1/4" |
| Face Dimension (Decimal Inch) | 0.250" |
| Neck Diameter (Decimal Inch) | 0.3680" |
| Overall Length (Inch) | 6" |
| Overall Length (Decimal Inch) | 6.00" |
| Split Length (Decimal Inch) | 0.320" |
| Tooth Width (Decimal Inch) | 0.3000" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Minimum Bore Diameter (Decimal Inch):
0.4900"
Maximum Bore Depth (Inch):
4-1/2"
Maximum Bore Depth (Decimal Inch):
4.500"
Material:
Carbide
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Overall Length (Inch):
6"
Overall Length (Decimal Inch):
6.00"
Finish/Coating:
Uncoated
Ships:
From Partner Facility
IsDiscontinued:
