Product Specifications
| # Manufacturer Number | 0713787 |
| Diameter (mm) | 10.40mm |
| Shank Size (mm) | 10.00mm |
| Flute Length (mm) | 48.00mm |
| Overall Length (mm) | 90.00mm |
| Drill Point Angle | 180 Degree |
| Number of Flute | 2 |
| Material | Carbide |
| Finish / Coating | Aqua EX |
| Coolant Through | No |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Drill Bit Size (Inch):
2/5";Drill Bit Size (Decimal Inch)=0.4094""
Drill Bit Size (mm):
10.40mm
Flute Length (Inch):
1-8/9";Flute Length (Decimal Inch)=1.8898""
Flute Length (mm):
48.00mm
Drill Point Angle:
180 Degree
Overall Length (Inch):
3-1/2";Overall Length (Decimal Inch)=3.5433""
Overall Length (mm):
90.00mm
Material:
Carbide
Finish/Coating:
Aqua EX
Coolant Through:
No
