The EXOCARB AERO-H is a TiAlN coated carbide drill designed for composite and metal stacks. It features a high helix and parabolic flute form for improved chip evacuation as well as corner radius and end gash to resist chipping.
Features & Benefits:
- Parabolic flute form: Improves chip evacuation
- Corner radius and end gash: Resists chipping
- TiALN coating: Provides a sharper Cutting Edge to reduce burr height
Product Specifications
| Manufacturer Part Number | 573219111 |
| Cutting Diameter Tolerance (Decimal Inch) | +0 / -0.0011" |
| Cutting Direction | Right Hand |
| Diameter (Decimal Inch) | 0.192" |
| Diameter (mm) | 4.86mm |
| Diameter (Wire) | 11 |
| Flute Length (mm) | 50.80mm |
| Helix Angle (Degree) | 40 Degree |
| Helix Direction | Right Hand |
| List Name | AERO-H |
| Number of Flutes | 2 |
| Overall Length (mm) | 101.60mm |
| Point Angle (Degree) | 140 Degree |
| Shank Diameter (mm) | 4.86mm |
| Shank Tolerance | h6 |
| Material | Carbide |
| Coating | TiAlN |
| Product Type | Jobber Length Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
OSG
Cutting Direction:
Right Hand
Diameter (Decimal Inch):
0.1920"
Diameter (mm):
4.86mm
Diameter (Wire):
11
Flute Length (mm):
50.80mm
Helix Angle:
40 Degree
Number of Flutes:
2
Overall Length (mm):
101.60mm
Point Angle:
140 Degree
Shank Diameter (mm):
4.86mm
Material:
Carbide
Finish/Coating:
TiAlN
interval quantity:
1
