OSG 82200621 | A Brand 5/16" Diameter x 0.438" LOC x 4.000" OAL x 0.015" Radius x 37 to 40 Degree Helix Angle 4 Flute DUARISE Coated Carbide Corner Radius End Mill

$107.71
Brand:
OSG
Corner Radius (Decimal Inch):
0.0150"
Cutting Direction:
Right Hand
Diameter (Inch):
5/16"
Diameter (Decimal Inch):
0.3130"
Helix Angle:
37 to 40 Degree
Length of Cut (Decimal Inch):
0.4380"
Neck Diameter (Decimal Inch):
0.2950"
Neck Length (Decimal Inch):
1.5620"
Number of Flutes:
4
Overall Length (Decimal Inch):
4.0000"
Shank Diameter (Decimal Inch):
0.3130"
Material:
Carbide
Finish/Coating:
DUARISE
interval quantity:
1
SKU:
25288755
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 82200621 | A Brand 5/16" Diameter x 0.438" LOC x 4.000" OAL x 0.015" Radius x 37 to 40 Degree Helix Angle 4 Flute DUARISE Coated Carbide Corner Radius End Mill

Advanced Performance Anti-Vibration Carbide End Mills

Features & Benefits:

  • Positive Rake Angle: Reduces Cutting Force
  • High Rigidity: Improves milling accuracy
  • New Flute Form: Facilitates excellent chip evacuation
  • Duarise Coating: Minimizes thermal cracks
Product Specifications
Manufacturer Part Number82200621
Corner Radius (Decimal Inch)0.015"
Cutting Diameter Tolerance (Decimal Inch)+0 / -0.0008"
Cutting DirectionRight Hand
Diameter (Inch)5/16"
Diameter (Decimal Inch)0.313"
Helix Angle (Degree)37 to 40 Degree
Helix DirectionRight Hand
Length of Cut (Decimal Inch)0.438"
List NameAE-LN-CR-VMS
Neck Diameter (Decimal Inch)0.295"
Neck Length (Decimal Inch)1.562"
Number of Flutes4
Overall Length (Decimal Inch)4.000"
Radius Tolerance (Decimal Inch)+/- 0.0008"
Shank Diameter (Decimal Inch)0.313"
Shank ToleranceShrink Fit
MaterialCarbide
CoatingDUARISE
Product TypeCorner Radius End Mill
