OSG VG434-1876 | HY-PRO CARB 0.188" Diameter x 0.188" Shank x 0.438" LOC x 0.030" Radius x 2.000" OAL x 35 Degree Helix Angle 4 Flute TiAlN Coated Carbide Corner Radius End Mill

$22.45
Brand:
OSG
Diameter (Decimal Inch):
0.1880"
Overall Length (Decimal Inch):
2.0000"
Shank Diameter (Decimal Inch):
0.1880"
Helix Angle:
35 Degree
Length of Cut (Decimal Inch):
0.4380"
Number of Flutes:
4
Material:
Carbide
Finish/Coating:
TiAlN
Corner Radius (Decimal Inch):
0.0300"
Cutting Direction:
Right Hand
interval quantity:
1
SKU:
25154496
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG VG434-1876 | HY-PRO CARB 0.188" Diameter x 0.188" Shank x 0.438" LOC x 0.030" Radius x 2.000" OAL x 35 Degree Helix Angle 4 Flute TiAlN Coated Carbide Corner Radius End Mill

High Performance Variable Index End Mills for Difficult to Machine Materials

Features & Benefits:

  • Unequal Flute Spacing: Reduces vibration from harmonic vibration, increasing life and enabling more aggressive milling
  • Raised Land Configuration: Provides additional stability when taking deeper depths of cut for more consistent performance during roughing
  • TiAIN Coating: Provides stable Wear Resistance in high temperature milling conditions
Product Specifications
Manufacturer Part NumberVG434-1876
Corner Radius (Decimal Inch)0.030"
Diameter (Decimal Inch)0.188"
Length of Cut (Decimal Inch)0.438"
Number of Flutes4
Overall Length (Decimal Inch)2.000"
Shank Diameter (Decimal Inch)0.188"
CoatingTiAlN
MaterialCarbide
Helix DirectionRight Hand
Helix Angle (Degree)35 Degree
Product TypeCorner Radius End Mill
