Features:
- Made from high-carbon bearing steel for improved flexibility
- 0.0004" max. T.I.R
- Clamping range 1/64"
- Precision ground and hand inspected
Product Specifications
| Collet Series | PG100 |
| Overall Diameter (Inch) | 1.379" |
| Body Width (Inch) | 1.379" |
| Capacity (Inch) | 0.406-0.422" |
| Min Capacity (Inch) | 0.406" |
| Max Capacity (Inch) | 0.422" |
| Overall Length (Inch) | 2.375" |
| Shank Size (Inch) | 27/64" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Parlec
Collet Series:
PG100
Size (Inch):
27/64"
Size (mm):
10.72mm
Size (Decimal Inch):
0.42"
Overall Length (Inch):
2-3/8"
Overall Length (mm):
60.33mm
