Features:
- Cuts UNC, UNF, UNEF, and UNS threads
- Cuts UNJ threads (internal only)
- Excels in difficult-to-thread materials
- AlTiN+ coating extends tool life
Product Specifications
| Manufacturer Part Number | TMLR470-11A |
| Cutting Diameter (Decimal Inch) | 0.470" |
| Neck Diameter (Decimal Inch) | 0.335" |
| Shank Diameter (Decimal Inch) | 0.500" |
| Overall Length (Decimal Inch) | 4.000" |
| Minium ID Thread | 5/8-11" |
| Length (Decimal Inch) | 0.045" |
| Length of Cut (Decimal Inch) | 1.200" |
| Number of Flute | 4 |
| Thread Pitch | 5/8-11" |
| Material | Solid Carbide |
| Coating | AlTiN |
| Product Type | Helical Flute Thread Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Scientific Cutting Tools
Cutter Diameter (Inch):
15/32"
Cutter Diameter (Decimal Inch):
0.4700"
Cutter Diameter (mm):
11.94mm
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Number of Flutes:
4
Length of Cut (Inch):
1-13/64"
Length of Cut (Decimal Inch):
1.2000"
Length of Cut (mm):
30.48mm
Finish/Coating:
AlTiN
Material:
Solid Carbide
