Seco Tools 03273098 | XNHQ1407 Size x 0.122" Radius 4 Cutting Edge Carbide Disc Milling Insert

$53.90 $42.58
(You save $11.32)
Brand:
Seco Tools
Corner Radius (Decimal Inch):
0.1220"
Corner Radius (mm):
3.10mm
Insert Hand:
Neutral
Insert Length (Decimal Inch):
0.5669"
Insert Length (mm):
14.40mm
Insert Width (Decimal Inch):
0.2953"
Insert Width (mm):
7.50mm
interval quantity:
10
SKU:
23287230
UPC:
Weight:
0.03 LBS
Minimum Purchase:
10 units
Shipping:
Free Shipping
Seco Tools 03273098 | XNHQ1407 Size x 0.122" Radius 4 Cutting Edge Carbide Disc Milling Insert

Product Specifications
Manufacturer Part Number03273098
Insert Length (Decimal Inch)0.567"
Insert Length (mm)14.40mm
Wiper Edge Length (Decimal Inch)0.028"
Wiper Edge Length (mm)0.70mm
Cutting Edge Effective Length (Decimal Inch)0.516"
Cutting Edge Effective Length (mm)13.10mm
Corner Radius (Decimal Inch)0.122"
Corner Radius (mm)3.10mm
Cutting Edge Count4
Cutting Geometry Type TechnicalM11
Insert Size And ShapeXNHQ1407
Insert Rake Angle (Degree)16 Degree
Insert HandNeutral
MaterialCarbide
Product TypeDisc Milling Insert

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Seco Tools
Corner Radius (Decimal Inch):
0.1220"
Corner Radius (mm):
3.10mm
Insert Hand:
Neutral
Insert Length (Decimal Inch):
0.5669"
Insert Length (mm):
14.40mm
Insert Width (Decimal Inch):
0.2953"
Insert Width (mm):
7.50mm
interval quantity:
10
