Product Specifications
| Manufacturer Part Number | 10008189 |
| Body Diameter (Decimal Inch) | 2.047" |
| Body Diameter (mm) | 52.00mm |
| Maximum Connection Bore Diameter (Decimal Inch) | 0.787" |
| Maximum Connection Bore Diameter (mm) | 20.00mm |
| Body Length (Decimal Inch) | 2.750" |
| Body Length (mm) | 69.85mm |
| Functional Length Secondary (Decimal Inch) | 2.516" |
| Functional Length Secondary (mm) | 63.90mm |
| Protruding Length (Decimal Inch) | 3.500" |
| Protruding Length (mm) | 88.90mm |
| Clamping Length (Decimal Inch) | 1.929" |
| Clamping Length (mm) | 49.00mm |
| Overall Length (Decimal Inch) | 6.187" |
| Overall Length (mm) | 157.15mm |
| Data Chip Provision | 1 |
| Maximum Rotational Speed (rpm) | 18000 rpm |
| Product Type | End Mill Holder |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Seco Tools
Body Diameter (Inch):
2-4/85"
Body Diameter (Decimal Inch):
2.0470"
Body Diameter (mm):
52.00mm
Overall Length (Inch):
6-3/16"
Overall Length (Decimal Inch):
6.1870"
Overall Length (mm):
157.15mm
interval quantity:
1
