Features:
- 3.5X clamping force of standard hydraulic chucks
- 74% thicker bore walls improve rigidity in heavy material removal applications
- Excellent vibration dampening properties enhances surface finish and extends tool life
Product Specifications
| Taper | CAT40 |
| Nose Diameter (Inch) | 1.94" |
| Body Diameter (Inch) | 1.94" |
| Overall Diameter (Inch) | 1.75" |
| Projection (Inch) | 2.54" |
| Nose Length (Inch) | 1.79" |
| Bore Depth (Inch) | 1.89" |
| Overall Length (Inch) | 5.2" |
