Features:
- 3.5X clamping force of standard hydraulic chucks
- 74% thicker bore walls improve rigidity in heavy material removal applications
- Excellent vibration dampening properties enhances surface finish and extends tool life
Product Specifications
| Taper | SBT30 |
| Nose Diameter (Inch) | 1.65" |
| Body Diameter (Inch) | 1.65" |
| Overall Diameter (Inch) | 1.25" |
| Projection (Inch) | 3.54" |
| Nose Length (Inch) | 2.68" |
| Bore Depth (Inch) | 1.89" |
| Overall Length (Inch) | 5.45" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
BT30
Body Diameter (Decimal Inch):
1.6500"
Nose Diameter (Decimal Inch):
1.6500"
Overall Length (Decimal Inch):
5.4500"
Overall Diameter (Decimal Inch):
1.2500"
Bore Size (Inch):
3/4"
Bore Depth (Decimal Inch):
1.8900"
interval quantity:
1
