Features:
- H5 bore tolerance for improved concentricity and tool life
- Balance to 15,000 RPM @ G6.3
- Coolant tubes for through-spindle coolant
Product Specifications
| Taper | HSK63A |
| Body Diameter (Inch) | 1.89" |
| Body Width (Inch) | 1.89" |
| Overall Diameter (Inch) | 2.48" |
| Bore Size (Inch) | 0.313" |
| Projection (Inch) | 4" |
| Nose Diameter (Inch) | 0.875" |
| Overall Length (Inch) | 5.26" |
