Features:
- Coolant channels in the bore direct coolant precisely to the cutting edge
- Effective removal of chips for faster feed rates
- H5 bore tolerance for improved concentricity and tool life
Product Specifications
| Taper | SCAT40 |
| Body Diameter (inch) | 1.75" |
| Body Width (inch) | 1.75" |
| Overall Diameter (Inch) | 2.5" |
| Bore Size (Inch) | 0.75" |
| Projection (Inch) | 6" |
| Nose Diameter (Inch) | 1.75" |
| Overall Length (inch) | 8.69" |
