Features:
- High speed steel
- Taps are on blanks that meet ANSI specifications
- Bottom - 2.5 Thread Chamfer for blind hole tapping
- Lube grooves for lubrication and venting in blind holes
- Thread forming taps have no flutes or cutting edges and provide chipless tapping
- Uncoated is great for lead, stainless steels, carbon steels, aluminum and most other ductile materials producing stringy chips
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT82850 |
| Shank Diameter (Inch) | 0.1680" |
| Thread Length (Inch) | 0.7500" (3/4) |
| Overall Length (Inch) | 2.1250" (2-1/8) |
| Thread Size (Inch) | #8-32 |
| Across Flat (Inch) | 0.1310" |
| End Length (Inch) | 0.2500" (1/4) |
| Lube Grooves | 1 |
| Limit | H3 |
| Coating | Uncoated |
| Substrate | High Speed Steel |
| Type | Bottom |
| Product Type | Thread Forming Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Shank Diameter (Decimal Inch):
0.1680"
Shank Diameter (mm):
4.27mm
Length of Cut (Inch):
3/4"
Length of Cut (Decimal Inch):
0.7500"
Length of Cut (mm):
19.05mm
Overall Length (Inch):
2-1/8"
Overall Length (Decimal Inch):
2.1250"
Overall Length (mm):
53.98mm
Finish/Coating:
Uncoated
Material:
High Speed Steel
interval quantity:
1
