Features:
- For optimal results, use a Taper Tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- Taps are on blanks that meet ANSI specifications
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT90222 |
| Shank Diameter | 0.1940" |
| Overall Length (Inch) | 2.3750" (2-3/8) |
| Length of Cut (Inch) | 0.8750" (7/8) |
| Thread Size | 10"-24 |
| End Length (Inch) | 0.2500" (1/4) |
| Type | Bottom |
| Thread Limit | H2 |
| Number of Flutes | 4 |
| Coating | Uncoated |
| Substrate | high speed steel |
| Product Type | Straight Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
