Product Specifications
| EDP Number | 99098CN |
| Diameter (Decimal Inch) | 2.0000" |
| Diameter (Inch) | 2" |
| Diameter (mm) | 50.80mm |
| Shank Diameter (Decimal Inch) | 1.2500" |
| Shank Diameter (Inch) | 1-1/4" |
| Shank Diameter (mm) | 31.75mm |
| Length of Cut (Decimal Inch) | 3.0000" |
| Length of Cut (Inch) | 3" |
| Length of Cut (mm) | 76.20mm |
| Overall Length (Decimal Inch) | 5.5000" |
| Overall Length (Inch) | 5-1/2" |
| Overall Length (mm) | 139.70mm |
| Series | E2039 |
| Shank Style | Flat |
| Helix Angle | 30 Degree |
| Number of Flutes | 8 |
| Coating | TiN |
| Cut Type | Center Cutting |
| Cutting Direction | Right |
| Type | Square End Mills |
| Application | N |
| Material | HSSCo8 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Helix Angle:
30 Degree
Cutting Direction:
HSSCo8 8 Flute Medium Length Center Cutting
interval quantity:
1
