Features:
Product Specifications
| EDP Number | BG742GB |
| Thread Diameter (Inch) | 7/8" |
| Diameter (Decimal Inch) | 0.8750" |
| Diameter (mm) | 22.23mm |
| Thread Pitch (TPI) | 9 TPI |
| Overall Length (Decimal Inch) | 5.5120" |
| Overall Length (mm) | 140.00mm |
| Thread Length (Decimal Inch) | 0.8270" |
| Thread Length (mm) | 21.01mm |
| Square Length (Decimal Inch) | 0.7500" |
| Square Length (mm) | 19.05mm |
| Shank Diameter (Decimal Inch) | 0.6970" |
| Shank Diameter (mm) | 17.70mm |
| Square Size (Decimal Inch) | 0.5230" |
| Square Size (mm) | 13.28mm |
| Neck Diameter (Decimal Inch) | 0.6850" |
| Neck Diameter (mm) | 17.40mm |
| Drill Size (Decimal Inch) | 0.7740" |
| Drill Size (mm) | 19.66mm |
| Useable Length (Decimal Inch) | 2.8150" |
| Useable Length (mm) | 71.50mm |
| Series | BG-GB |
| Number of Flutes | 4 |
| Thread Series | UNC |
| Thread Class | 2B |
| Chamfer Length | 2P-3P |
| Tap Type | SPFL |
| Chamfer Type | Modified Bottoming |
| Coating | Hardslick |
| Material | HSSE-V3 |
| Blank Standard | DIN/ANSI |
| Helix Angle (Degree) | 40 Degree |
| Coolant Through | No |
| Trade Name | Oil Field Taps |
| Tap Type | Spiral Flute |
| Product Type | Spiral Flute Modified Bottom Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Size (Inch):
7/8"
Thread Size (Decimal Inch):
0.8750"
Thread Size (mm):
22.23mm
Class of Fit:
2B
Number of Flutes:
4
Chamfer:
2P-3P
Material:
HSSE-V3
Finish/Coating:
Hardslick
Through Coolant:
No
Threads per Inch (TPI):
9 TPI
