Product Specifications
| Diameter (Decimal Inch) | D6082 |
| Diameter (Decimal Inch) | 0.0860" |
| Diameter (mm) | 2.18mm |
| Overall Length (Decimal Inch) | 1.7500" |
| Overall Length (mm) | 44.45mm |
| Thread Length (Decimal Inch) | 0.1570" |
| Thread Length (mm) | 3.99mm |
| Square Length (Decimal Inch) | 0.1900" |
| Square Length (mm) | 4.83mm |
| Shank Diameter (Decimal Inch) | 0.1410" |
| Shank Diameter (mm) | 3.58mm |
| Square Size (Decimal Inch) | 0.1100" |
| Square Size (mm) | 2.79mm |
| Neck Diameter (Decimal Inch) | 0.5770" |
| Neck Diameter (mm) | 2.29mm |
| Drill Size (Decimal Inch) | 0.0698" |
| Drill Size (mm) | 1.77mm |
| Useable Length (Decimal Inch) | 0.4330" |
| Useable Length (mm) | 11.00mm |
| Number Of Flutes | 3 |
| Size | #2 |
| Tap Type | SPFL |
| Size & Pitch | #2-56 |
| Pitch | 56 TPI |
| Thread Series | UNC |
| Pitch Limit | H2 |
| Chamfer Type | Modified Bottoming |
| Chamfer Length | 2P-3P |
| Coating | Hardslick |
| Material | P-HSS |
| Blank Standard | 302A |
| Helix Angle | 15 Degree |
| Coolant Through | No |
| Product Type | Spiral Flute Tap |
