Product Specifications
| Manufacturer Part Number | DH453027 |
| Cutting Diameter (Inch) | 5/47" |
| Cutting Diameter (Decimal Inch) | 0.106" |
| Cutting Diameter (mm) | 2.70mm |
| Shank Diameter (Inch) | 3/19" |
| Shank Diameter (Decimal Inch) | 0.157" |
| Shank Diameter (mm) | 4.00mm |
| Flute Length (Inch) | 1-2/11" |
| Flute Length (Decimal Inch) | 1.181" |
| Flute Length (mm) | 30.00mm |
| Overall Length (Inch) | 2-3/5" |
| Overall Length (Decimal Inch) | 2.598" |
| Overall Length (mm) | 66.00mm |
| Point Length (Decimal Inch) | 0.019" |
| Point Length (mm) | 0.49mm |
| Number of Flutes | 2 |
| Shank Tolerance | h6 |
| Hole Tolerance | m7 |
| Material | Carbide |
| Coating | TiAIN |
| Product Type | Dream Drill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Diameter
(Inch):
5/47";Diameter
(Decimal Inch)=0.1060"""""
Diameter
(mm):
2.70mm
Shank Diameter
(Inch):
3/19";Shank Diameter
(Decimal Inch)=0.1570"""""
Shank Diameter
(mm):
4.00mm
Flute Length
(Inch)):
1-2/11";Flute Length
(Decimal Inch))=1.1810"""""
Flute Length
(mm):
30.00mm
Point Length
(Inch):
1/53";Point Length (Decimal Inch)=0.0190"""""
Point Length
(mm):
0.49mm
Helix
Angle:
30 Degree
Coating:
TiAIN
Material:
Carbide
Cutting
Direction:
Right Hand
Number of Flutes:
2
interval quantity:
1
