Product Specifications
| # Manufacturer Number | EMB79024 |
| Diameter (Decimal Inch) | 0.3750" |
| Diameter (Inch) | 3/8" |
| Diameter (mm) | 9.53mm |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter (mm) | 9.53mm |
| Length og Cut (Decimal Inch) | 0.8750" |
| Length og Cut (Inch) | 7/8" |
| Length og Cut (mm) | 22.23mm |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (mm) | 63.50mm |
| 0.1875" | 0.1875" |
| Ball Nose Radius (Inch) | 3/16" |
| Ball Nose Radius (mm) | 4.76mm |
| Number of Flutes | 4 |
| Shank Style | Flat |
| Helix Angle | Variable |
| Coating | AlTiN |
| Material | Carbide |
| Cut Type | Center |
| Series | EMB79 |
| Application | PMS |
| Cutting Direction | Right |
| Length Type | Ball Nose |
| Product Type | Ball End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Finish/Coating:
AlTiN
Cutting Direction:
Right
interval quantity:
1
