Product Specifications
Manufacturer Part Number | GM839060 |
Mill Diameter (Inch) | 13/55" |
Mill Diameter (Decimal Inch) | 0.2362" |
Mill Diameter (mm) | 6.00mm |
Shank Diameter (Inch) | 13/55" |
Shank Diameter (Decimal Inch) | 0.2362" |
Shank Diameter (mm) | 6.00mm |
Length of Cut (Inch) | 8/29" |
Length of Cut (Decimal Inch) | 0.2756" |
Length of Cut (mm) | 7.00mm |
Overall Length (Inch) | 2-1/6" |
Overall Length (Decimal Inch) | 2.1654" |
Overall Length (mm) | 55.00mm |
Corner Radius (Inch) | 3/127" |
Corner Radius (Decimal Inch) | 0.0236" |
Corner Radius (mm) | 0.60mm |
LBS (Inch) | 43/78" |
LBS (Decimal Inch) | 0.5512" |
LBS (mm) | 14.00mm |
Neck Diameter (Inch) | 15/68" |
Neck Diameter (Decimal Inch) | 0.2205" |
Neck Diameter (mm) | 5.60mm |
Helix (Degree) | 30 Degree |
Number of Flute | 4 |
Shank Type | Plain |
Material | Carbide |
Product Type | Corner Radius End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Mill Diameter (Inch):
13/55"
Mill Diameter (Decimal Inch):
0.2362"
Mill Diameter (mm):
6.00mm
Number of Flutes:
4
Length of Cut (Inch):
8/29"
Length of Cut (Decimal Inch):
0.2756"
Length of Cut (mm):
7.00mm
Material:
Carbide
Overall Length (Inch):
2-1/6"
Overall Length (Decimal Inch):
2.1654"
Overall Length (mm):
55.00mm
Shank Diameter (Inch):
13/55"
Shank Diameter (Decimal Inch):
0.2362"
Shank Diameter (mm):
6.00mm
Corner Radius (Inch):
3/127"
Corner Radius (Decimal Inch):
0.0236"
Corner Radius (mm):
0.60mm
