Product Specifications
| Manufacturer Part Number | T7315138 |
| Diameter (Decimal Inch) | 0.0787" |
| Diameter (mm) | 2.00mm |
| OAL (Decimal Inch) | 1.7500" |
| OAL (mm) | 44.45mm |
| Thread Length (Decimal Inch) | 0.4400" |
| Thread Length (mm) | 11.18mm |
| Square Length (Decimal Inch) | 0.1900" |
| Square Length (mm) | 4.83mm |
| Shank Diameter (Decimal Inch) | 0.1410" |
| Shank Diameter (mm) | 3.58mm |
| Square Size (Decimal Inch) | 0.1100" |
| Square Size (mm) | 2.79mm |
| Drill Size (Decimal Inch) | 0.0644" |
| Drill Size (mm) | 1.64mm |
| Useable Length (Decimal Inch) | 0.4400" |
| Useable Length (mm) | 11.18mm |
| Length/Diameter | 2xD |
| Number of Flutes | 3 |
| Thread Diameter (Inch) | M2 |
| Thread Pitch | 0.4 TPI |
| Series | T7315 |
| Thread Series | M |
| Pitch Limit | D3 |
| Chamfer Length | 1.5P-2P |
| Shank Type | Square |
| Chamfer Type | Bottoming |
| Helix Angle | 0 Degree |
| Finish | Bright |
| Material | HSS |
| Blank Standard | 302 |
| Tap Type | Hand |
