Product Specifications
| EDP Number | TQ808766 |
| Size | M22 |
| Pitch | 1.5 TPI |
| Diameter (Decimal Inch) | 0.8661" |
| Diameter (mm) | 22.00mm |
| Overall Length (Decimal Inch) | 4.6900" |
| Overall Length (mm) | 119.13mm |
| Thread Length (Decimal Inch) | 1.3390" |
| Thread Length (mm) | 34.01mm |
| Square Length (Decimal Inch) | 0.7500" |
| Square Length (mm) | 19.05mm |
| Shank Diameter (Decimal Inch) | 0.6970" |
| Shank Diameter (mm) | 17.70mm |
| Square Size (Decimal Inch) | 0.5230" |
| Square Size (mm) | 19.05mm |
| Neck Diameter (Decimal Inch) | 0.6850" |
| Neck Diameter (mm) | 17.40mm |
| Drill Size (Decimal Inch) | 0.8124" |
| Drill Size (mm) | 20.64mm |
| Useable Length (Decimal Inch) | 2.2200" |
| Useable Length (mm) | 56.39mm |
| Number of Flutes | 4 |
| Series | TQ808 |
| Chamfer Length | 4P-5P |
| Blank Standard | 302A |
| Thread Series | MF |
| Pitch Limit | D6 |
| Coating | Steam Oxide |
| Material | P-HSS |
| Helix Angle (Degree) | 0 Degree |
| Length/Diameter | 3.0xD |
| Shank Type | Square |
| Coolant Through | No |
| Trade Name | YG Tap Hard Steel |
| Tap Type | Spiral Point |
| Chamfer Type | Plug |
| Product Type | Spiral Point Plug Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Thread Limit:
D6
Number of Flutes:
4
Thread Standard:
MF
Chamfer:
4P-5P
Finish/Coating:
Steam Oxide
Material:
P-HSS
Through Coolant:
No
