Fullerton Tool 25025 | 1/8" Diameter x 1/8" Shank x 1/2" LOC x 1-1/2" OAL 5 Flute FC1 Solid Carbide Corner Radius End Mill

$78.28 $49.32
(You save $28.96)
Ships:
From Partner Facility
Brand:
Fullerton Tool
Mill Diameter (Inch):
1/8"
Mill Diameter (Decimal Inch):
0.1250"
Mill Diameter (mm):
3.18mm
Number of Flutes:
5
End Type:
Corner Radius
Corner Radius (mm):
0.25mm
Length of Cut (Inch):
1/2"
Length of Cut (Decimal Inch):
0.5000"
Length of Cut (mm):
12.70mm
Material:
Solid Carbide
Finish/Coating:
FC1
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Application:
Carbon Composites, Fiberglass, Fiber Reinforced Materials, Plastics, and Green Ceramics
Single or Double End:
Single
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.10mm
Series:
5500 MATRX
Ships:
From Partner Facility
Merchandising Boost Rule:
Yes
SKU:
25055610
UPC:
Weight:
0.11 LBS
Shipping:
Calculated at Checkout
Fullerton Tool 25025 | 1/8" Diameter x 1/8" Shank x 1/2" LOC x 1-1/2" OAL 5 Flute FC1 Solid Carbide Corner Radius End Mill

Features

  • The 5500 MATRX is a 5-flute, high performance end mill that allows for ultimate material removal rates in carbon composites, fiberglass, fiber reinforced materials, plastics, and green ceramics
  • Its high shear and low cutting forces provide a clean edge with minimal material delamination or tearing of fibers
  • The 5500 MATRX is stocked uncoated and with FC-1 coating

Product Specifications
Mill Diameter (Inch) 1/8"
Cutting Flute Length (Inch) 1/2"
Shank Diameter (Inch) 1/8"
Overall Length (Inch) 1-1/2"
Mill Diameter (Decimal Inch) 0.1250"
Cutting Flute Length (Decimal Inch) 0.5000"
Shank Diameter (Decimal Inch) 0.1250"
Overall Length (Decimal Inch) 1.5000"
Mill Diameter (mm) 3.18mm
Cutting Flute Length (mm) 12.70mm
Shank Diameter (mm) 3.18mm
Overall Length (mm) 38.10mm
Radius (mm) 0.25mm
Finish/Coating FC1
Number of Flutes 5
Helix Angle 35 Degree
Flute Spiral Direction Right Hand Spiral
Cutting Direction Right Hand Cutting
Coolant Thorugh (Yes/No) No
