Product Specifications
| EDP Number | EE515100 |
| Diameter (Decimal Inch) | 0.3937" |
| Diameter (Inch) | 37/94" |
| Diameter (mm) | 10.00mm |
| Shank Diameter (Decimal Inch) | 0.3937" |
| Shank Diameter (Inch) | 37/94" |
| Shank Diameter (mm) | 10.00mm |
| Length of Cut (Decimal Inch) | 0.8661" |
| Length of Cut (Inch) | 13/8" |
| Length of Cut (mm) | 22.00mm |
| Overall Length (Decimal Inch) | 2.8346" |
| Overall Length (Inch) | 2-5/6" |
| Overall Length (mm) | 72.00mm |
| Number of Flutes | 4 |
| Series | EG908 |
| Helix Angle (Degree) | 30 Degree |
| Coating | TiAlN |
| Material | Premium HSS-PM |
| Shank Style | Flat |
| Cut Type | Center Cut |
| Length Type | Short |
| Application | P,M,S |
| Cutting Direction | Right Hand |
| Product Type | Square End Mill |
