Product Specifications
| Cutter Diameter (Decimal Inch) | 0.2640" |
| Neck Diameter (Decimal Inch) | 0.1860" |
| Length of Cut (Inch) | 3/16" |
| Length of Cut (Decimal Inch) | 0.1875" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Max Depth of Thread (Inch) | 1/2" |
| Max Depth of Thread (Decimal Inch) | 0.5000" |
| Included Angle | 60 Degree |
| Number of Flutes | 3 |
| Size (Inch) | 3/8-16 |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN Nano |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Thread Size (Inch):
3/8-16
Cutter Diameter (Decimal Inch):
0.2640"
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3125"
Number of Flutes:
3
Length of Cut (Inch):
3/16"
Length of Cut (Decimal Inch):
0.1875"
Finish/Coating:
AlTiN Nano
Material:
Carbide
Through Coolant:
No
Ships:
From Partner Facility
interval quantity:
1
