Product Specifications
| Cutter Diameter (Inch) | 3/16" |
| Cutter Diameter (Decimal Inch) | 0.1875" |
| Coating | Uncoated |
| Flutes | 2 |
| Length of Cut (Decimal Inch) | 0.200" |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Corner Radius (Decimal Inch) | 0.010" |
| Neck Diameter (Decimal Inch) | 0.1830" |
| Overall Length (Inch) | 3" |
| Overall Length (Decimal Inch) | 3.00" |
| Overall Reach (Inch) | 1-1/2" |
| Overall Reach (Decimal Inch) | 1.500" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Mill Diameter (Inch):
3/16"
Mill Diameter (Decimal Inch):
0.1875"
Number of Flutes:
2
End Type:
Corner Radius
Corner Radius (Decimal Inch):
0.010"
Length of Cut (Decimal Inch):
0.200"
Overall Reach (Inch):
1-1/2"
Overall Reach (Decimal Inch):
1.500"
Material:
Carbide
Finish/Coating:
Uncoated
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.00"
Ships:
From Partner Facility
