Product Specifications
| # Manufacturer Number | 0718233 |
| Diameter (mm) | 8.30mm |
| Shank Size (mm) | 8.00mm |
| Flute Length (mm) | 37.00mm |
| Overall Length (mm) | 130.00mm |
| Drill Point Angle | 180 |
| Number of Flute | 2 |
| Material | Carbide |
| Finish / Coating | Aqua EX |
| Coolant Through | No |
| Cutting Direction | Right |
| Flute Type | Conventional Spiral |
| Shank Type | Endmill Type Shank |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Nachi
Drill Bit Size (Inch):
1/3";Drill Bit Size (Decimal Inch)=0.3333""
Drill Bit Size (mm):
8.47mm
Drill Point Angle:
180 Degree
Flute Length (Inch):
1-1/2";Flute Length (Decimal Inch)=1.4567""
Flute Length (mm):
37.00mm
Overall Length (Inch):
5-1/8";Overall Length (Decimal Inch)=5.1181""
Overall Length (mm):
130.00mm
Material:
Carbide
Finish/Coating:
Aqua EX
Flute Type:
Conventional Spiral
Cutting Direction:
Conventional Spiral
Shank Type:
Endmill Type Shank
Coolant Through:
No
