Product Specifications
| EDP Number | EM832180 |
| Diameter (Decimal Inch) | 0.7100" |
| Diameter (Inch) | 17/24" |
| Diameter (mm) | 18.00mm |
| Shank Diameter (Decimal Inch) | 0.7087" |
| Chamfer Size (Decimal Inch) | 0.0200" |
| Shank Diameter (Inch) | 17/24" |
| Shank Diameter (mm) | 18.00mm |
| Length of Cut (Decimal Inch) | 0.9449" |
| Length of Cut (Inch) | 17/18" |
| Length of Cut (mm) | 24.00mm |
| Overall Length (Decimal Inch) | 3.3071" |
| Overall Length (mm) | 84.00mm |
| Overall Length (Inch) | 3-4/13" |
| Number of Flutes | 4 |
| Chamfer Size (mm) | 0.60mm |
| Series | EM832 |
| Helix Angle (Degree) | 20 Degree |
| Shank Style | Plain |
| Coating | ALTiN |
| Cut Type | Center Cut |
| Length Type | Short |
| Material | Carbide |
| Cutting Direction | Right |
| Application | P |
| Produce Type | Roughing End Mill |
