Product Specifications
| Manufacturer Part Number | UGMG22860 |
| Diameter (Inch) | 1" |
| Diameter (Decimal Inch) | 1.0000" |
| Diameter (mm) | 25.40mm |
| Shank Diameter (Inch) | 1" |
| Shank Diameter (Decimal Inch) | 1.0000" |
| Shank Diameter (mm) | 25.40mm |
| Length of Cut (Inch) | 2" |
| Length of Cut (Decimal Inch) | 2.0000" |
| Length of Cut (mm) | 50.80mm |
| Overall Length (Inch) | 5" |
| Overall Length (Decimal Inch) | 5.0000" |
| Overall Length (mm) | 127.00mm |
| Corner Radius (Inch) | 15/79" |
| Corner Radius (Decimal Inch) | 0.1900" |
| Corner Radius (mm) | 4.83mm |
| Number of Flutes | 6 |
| Helix Angle | Variable |
| Series | UGMG22 |
| Shank Style | Plain |
| Coating | Y-Coated |
| Material | Carbide |
| Cut Type | Center |
| Cutting Direction | Right |
| Length Type | Standard Length |
| Application | P, M, S |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
YG1
Diameter (Decimal Inch):
1.0000"
Diameter (Inch):
1"
Diameter (mm):
25.40mm
Shank Diameter (Decimal Inch):
1.0000"
Shank Diameter (Inch):
1"
Shank Diameter (mm):
25.40mm
Length of Cut (Decimal Inch):
2.0000"
Length of Cut (mm):
50.80mm
Overall Length (Decimal Inch):
5.0000"
Overall Length (Inch):
5"
Overall Length (mm):
127.00mm
Corner Radius (Decimal Inch):
0.1900"
Corner Radius (mm):
4.83mm
Number of Flutes:
6
Shank Style:
Plain
Helix Angle:
45 Degree
Finish/Coating:
Y-Coating
Material:
Carbide
Cut Type:
Center
Cutting Direction:
Right
interval quantity:
1
