Hand-Retractable Plungers-Knob Handle
Precision indexing plunger with a attractive knob handle for convenient retraction. Threaded-body version allows adjustment and can be secured with an optional Jam Nut. Provides high strength and durability in an extremely compact assembly. Hardened and ground plunger. Tip has a slight taper for easy alignment.
The non-locking type has a spring-loaded plunger that stays extended by spring force except when manually held in retracted position.
Material
| Item | Material | Heat Treat | Finish | DFARS | RoHS |
| Knub | Matte black fiber-reinforced nylon thermoplastic (textured surface for secure gripping, excellent impact resistance, operating temperatures to 230°F) | - | - | Yes | Yes |
| Plunger | Steel | Heat Treated | - | Yes | Yes |
| Body | Steel | - | Black Oxide | Yes | Yes |
| Jam Nut | Mild Steel | - | Black Oxide | Yes | Yes |
Parts Specification
| A Thread | B Diameter Nominal (inch) | B Diameter Actual (inch) | C (inch) | D (inch) | E (inch) | F Diameter | G (inch) | J (inch) | L (inch) | Initial End Force (lbs) | Final End Force (lbs) |
| 1/2-13 | 6" | 0.2354/0.2346" | 0.24" | 0.79" | 0.67" | 0.98 | 0.24" | 14" | 1.85" | 1.5 lbs. | 3.4 lbs. |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Carr Lane
Diameter:
0.9800"
Ships:
From Manufacturer
