Dormer E007M16 | 0.48" Diameter x 3.8125" OAL 3 Flute Bright Coated Spiral Flute Tap

$98.28
Ships:
From Partner Facility
Ships:
From Partner Facility
SKU:
15024383
UPC:
7320760580677
Weight:
2.95 LBS
Minimum Purchase:
1 unit
Shipping:
Free Shipping

Spiral flute tap with chamfer form C with a 2-3xP semi-bottoming lead, for ISO-Metric thread M16 with 2.00mm pitch and 6H class of fit, dimensions according to ANSI standard with 0.4800" shank and 0.3600" square drive, powder metallurgical HSS-E with bright finish and 45° helix angle for 2.5xD blind hole threading in free machining and plain carbon steel and wrought or cast aluminium.


Product Specifications
Connection Diameter (Inch)0.48"
Overall Length (Inch)3.8125"
No of Flutes3
Flute Helix Angle45
Thread Pitch (mm)2mm
Thread Diameter Size16
Material CodeHSS-E-PM
Thread Tolerance Class6H
Threading Length (Inch)0.7087"
Cutting DirectionRight Hand
CoatingBright
Tap Chamfer StyleC 2-3
Surface ColorBright Silver
Thread FormM-Metric coarse
