Thread size MF16 mm x 1.5 mm, with thread tolerance class 93707, and maximum threading depth 40 mm.
Product Specifications
| Manufacturer Part Number | E398M16X1.5 |
| Connection Diameter (mm) | 12.00mm |
| Connection Diameter (Decimal Inch) | 0.472" |
| Thread Diameter Size | 16" |
| Overall Length (Decimal Inch) | 3.937" |
| Overall Length (mm) | 100.00mm |
| Thread Length (mm) | 15.00mm |
| Thread Pitch (Decimal Inch) | 0.059" |
| Thread Pitch (mm) | 1.50mm |
| Premachined Hole Diameter (mm) | 14.50mm |
| Clamping Length (mm) | 12.00mm |
| Clamping Width (mm) | 9.00mm |
| Thread Length (Decimal Inch) | 0.591" |
| Clamping Length (Decimal Inch) | 0.472" |
| Clamping Width (Decimal Inch) | 0.354" |
| Premachined Hole Diameter (Decimal Inch) | 0.571" |
| Number of Flutes | 4 |
| Tap Chamfer Style | C 2 - 3 |
| Thread Form | MF - Metric Fine |
| Flute Geometry | Spiral Flute Geometry |
| Flute Helix Angle (Degree) | 48 Degree |
| Cutting Direction | Right Hand |
| Basic Standard Group | DIN 374 |
| Material | HSS-E-PM |
| Coating | TiCN |
| Product Type | Spiral Flute Tap |
| Country of Origin | Brazil |
