Thread size M4 mm x 0.7 mm, with thread tolerance class 93707, and maximum threading depth 10 mm.
Product Specifications
| Manufacturer Part Number | E698M4 |
| Connection Diameter (Decimal Inch) | 0.168" |
| Usable Length (mm) | 21.00mm |
| Thread Diameter Size | 4" |
| Overall Length (Decimal Inch) | 2.480" |
| Overall Length (mm) | 63.00mm |
| Thread Length (mm) | 7.00mm |
| Thread Pitch (Decimal Inch) | 0.028" |
| Thread Pitch (mm) | 0.70mm |
| Premachined Hole Diameter (mm) | 3.30mm |
| Usable Length (Decimal Inch) | 0.827" |
| Clamping Length (mm) | 6.00mm |
| Thread Length (Decimal Inch) | 0.276" |
| Clamping Length (Decimal Inch) | 0.236" |
| Clamping Width (Decimal Inch) | 0.129" |
| Premachined Hole Diameter (Decimal Inch) | 0.130" |
| Tolerance limit | D4 |
| Number of Flutes | 3 |
| Tap Chamfer Style | C 2 - 3 |
| Thread Form | M - Metric Coarse |
| Flute Geometry | Spiral Flute Geometry |
| Flute Helix Angle (Degree) | 48 Degree |
| Cutting Direction | Right Hand |
| Basic Standard Group | DIN/ANSI |
| Material | HSS-E-PM |
| Coating | TiCN |
| Product Type | Spiral Flute Tap |
| Country of Origin | Brazil |
