Product Specifications
| EDP Number | 99005 |
| Tool Holder Size | 4-25-L |
| Minimum Bore Diameter (mm) | 11.5mm |
| Minimum Bore Diameter (Inch) | 0.452" |
| Stem Diameter (mm) | 10mm |
| Stem Diameter (Inch) | 0.394" |
| Stem Length (mm) | 56mm |
| Stem Length (Inch) | 2.205" |
| Overall Length (mm) | 155mm |
| Overall Length (Inch) | 6.102" |
| Centering Plate | CP-1 |
| Mounting Screw | MS-1 |
| Driver | T08 |
| Through Tool Coolant | Yes |
| Product Type | Indexable Broaching Toolholder |
