Features:
- Higher tool life and performance. Variable helix design for reduced vibrations and stable cutting Coolant through design for maximum chip evacuation
- Axial
Product Specifications
| End Style | Corner Radius |
| End Type | Rough/Finish |
| Size | 20 mm |
| Applicable Material | Stainless Steel, Titanium, Nickel Alloys |
| Type | Corner Radius |
| Length Group | Regular |
| Features: | High performance geometry for aerospace materials. Coolant fed design |
| Coating | TIALN |
| Material | Carbide |
| Number of Flutes | 4 |
| Helix Angle (Degrees) | 38/40 Degree |
| Shank Diameter (mm) | 20 mm |
| Shank Tolerance | h6 |
| Shank Style | HA |
| Overall Length (mm) | 126 mm |
| Flute Length (mm) | 38 mm |
| Flute Direction | Right Hand |
| Corner Radius | 4 mm |
| Application | Finisher |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Emuge
Cutting Diameter (Decimal Inch):
0.7874"
Cutting Diameter (mm):
20.00mm
Shank Diameter (mm):
20.00mm
Corner Radius (mm):
4.00mm
Cutting Edge Material:
Carbide
Flute Length (mm):
38.00mm
Number of Flutes:
4
Flute Direction:
Right Hand
Finish/Coating:
TiAlN
Tool Type:
Corner Radius
Application:
Finishing
Overall Length (mm):
126.00mm
interval quantity:
1
